Juice Separation Food Decanter Centrifuge / Solid Bowl Centrifuges
Description:
Decanter centrifuges, also called solid bowl centrifuges, are generally designed as two-phase or three-phase machines and are extremely versatile. Taking advantage of the principle that the liquid and solid phase, with different density and mutually insoluble in the mixed liquid, gain different sedimentation speed in the centrifugal force field or gravity force field, separating stratification or causing the solid particles in the liquid to deposit can be achieved.
Separation principle
In the gravity force field or centrifugal force field, the liquid phase and the solid phase with different density and mutually insoluble in the mixed liquid, respectively gain different sedimentation speed, and thus separate and stratify. In the gravity force field, it is called gravity separation, while in the centrifugal force field it is called centrifugal separation.
The machine could deal with the material which range of concentration is large, small size which widely distributing. Solid particles are less than 0.5mm as rigid particles, and less than 10mm as non-rigid particles, the machine can be effectively treated. The decanter centrifuge is applicable to the separating of suspension containing solid-phase granules with a diameter greater than 0.005 mm and with the concentration being 2~40%.
Applications:
Animal protein
Fish oil and fishmeal by-product processing
Surimi processing
Soybean protein, peanut protein, corn protein, beer yeast.bone protein, bone blue, blood power dewatering, etc.
Vegetable protein
Extraction from soybeans, oilseeds, and some crops
Edible oil
Clarification of palm oil, olive oil, and pressed bean and seed oil
Juice
Extraction from fruit, citric acid, and coconut milk
Starch processing
Starch washing, dewatering, and clarification based on wheat, maize, tapioca, cassava, and potatoes
Specifications:
| Model | Drum | G-force | Capacity (m3/h) | Max solid discharge (m3/h) | Power (kW) | Weight (kg) | Overall size (L×W×H) (mm) |
| Diameter (mm) | Speed (rpm) | Length (mm) | Length-to-diameter rate |
| PDC-10-W | 250 | 5400 | 1000 | 4 | 4080 | 0.5~5 | 0.4 | 11/4 | 1000 | 2410 × 800 × 1080 |
| PDC-12-4-W | 300 | 4200 | 1200 | 4 | 3500 | 1~5 | 0.6 | 11/4 | 1200 | 2610 × 800 × 1080 |
| PDC-12-4.5-W | 300 | 4200 | 1350 | 4.5 | 3000 | 1~10 | 0.8 | 11/4 | 1400 | 2760 × 800 × 1080 |
| PDC-14-W | 355 | 4000 | 1600 | 4.5 | 3180 | 1~20 | 1.2 | 18.5/7.5 | 1800 | 3495 × 840 × 1180 |
| PDC-16-W | 400 | 3650 | 1800 | 4.5 | 3000 | 2~25 | 2 | 22/7.5 | 2500 | 3890 × 1020 × 1205 |
| PDC-18-4.4-W | 450 | 3200 | 2000 | 4.4 | 2600 | 3~35 | 2.8 | 30/11 | 3000 | 4297 × 1080 × 1385 |
| PDC-18-4.8-W | 450 | 3200 | 2150 | 4.8 | 2600 | 4~40 | 3 | 37/11 | 3200 | 4447 × 1080 × 1385 |
| PDC-20-4-W | 500 | 3000 | 2000 | 4 | 2500 | 5~45 | 3.2 | 37/11 | 3800 | 4330 × 1140 × 1470 |
| PDC-20-4.5-W | 500 | 3000 | 2250 | 4.5 | 2500 | 8~50 | 3.5 | 45/15 | 4000 | 4580 × 1140 × 1470 |
| PDC-21-W | 530 | 2900 | 2280 | 4.3 | 2500 | 15~65 | 5 | 55/15 | 5000 | 4924 × 1170 × 1540 |
| PDC-23-W | 580 | 2780 | 2500 | 4.3 | 2500 | 20~80 | 6.5 | 75/18.5 | 6500 | 5205 × 1270 × 1540 |
| PDC-26-W | 650 | 2500 | 2800 | 4.3 | 2270 | 25~110 | 8 | 75/18.5 | 7000 | 4300 × 1900 × 1350 |
Competitive Advantages:
High rotation speed, high G force, big length -diameter ratio.
Large capacity
Low vibration, low noises strong afford capacity
Multiple protecting apparatus, reliable running
Reliable gearbox system
Corrosion-resistant and resistant key parts
Flexible drive and speed adjust the mode
Famous and reliable electrical components
Reference Pictures
